Type & Size |
Breaking Load |
Safe Pulling Load |
Safe allowable |
Safe Total Pump |
Screen |
|---|---|---|---|---|---|
|
OD : 33 mm (1”) DN : 25 mm
|
|||||
|
V4-12.5
|
850
|
500
|
12.5
|
125
|
ORANGE
|
|
V4-15
|
1000
|
600
|
15
|
150
|
PURPLE
|
|
Crystal
|
1250
|
750
|
21
|
210
|
GREEN
|
|
Standard
|
1900
|
1100
|
30
|
300
|
RED
|
|
OD : 42 mm (1 1/4”) DN : 32 mm
|
|||||
|
V4-12.5
|
1300
|
800
|
12.5
|
125
|
ORANGE
|
|
V4-15
|
1550
|
900
|
15
|
150
|
PURPLE
|
|
Crystal
|
1800
|
1050
|
21
|
210
|
GREEN
|
|
Standard
|
2550
|
1500
|
25
|
250
|
RED
|
|
Heavy
|
3100
|
1800
|
30
|
300
|
BLUE
|
|
OD : 48 mm (1 1/2”) DN : 40 mm
|
|||||
|
V4-15
|
2000
|
1200
|
15
|
150
|
PURPLE
|
|
Crystal
|
2500
|
1500
|
21
|
210
|
GREEN
|
|
Standard
|
2950
|
1700
|
26
|
260
|
RED
|
|
Heavy
|
4050
|
2350
|
35
|
350
|
BLUE
|
|
OD : 60 mm (2”) DN : 50 mm
|
|||||
|
Medium
|
2450
|
1450
|
13
|
130
|
ORANGE
|
|
Crystal
|
3100
|
1850
|
17
|
170
|
GREEN
|
|
Standard
|
3600
|
2100
|
20
|
200
|
RED
|
|
Heavy
|
4700
|
2800
|
27
|
270
|
BLUE
|
|
Super Heavy
|
5600
|
3350
|
35
|
350
|
BLACK
|
|
OD : 75 mm (2 1/2”) DN : 65 mm
|
|||||
|
Medium
|
3100
|
1800
|
10
|
100
|
ORANGE
|
|
Standard
|
4650
|
2700
|
16
|
160
|
RED
|
|
Standard Plus
|
5900
|
3500
|
21
|
210
|
PURPLE
|
|
Heavy
|
7000
|
4200
|
26
|
260
|
BLUE
|
|
OD : 88 mm (3”) DN : 80 mm
|
|||||
|
Medium
|
4450
|
2600
|
11
|
110
|
ORANGE
|
|
Standard
|
6800
|
4000
|
17
|
170
|
RED
|
|
Heavy
|
9600
|
5650
|
26
|
260
|
BLUE
|
|
OD : 113 mm (4”) DN : 100 mm
|
|||||
|
Medium
|
6800
|
4000
|
10
|
100
|
ORANGE
|
|
Standard
|
10000
|
5900
|
15
|
150
|
RED
|
|
Heavy
|
16000
|
9350
|
26
|
260
|
BLUE
|
